Permanent magnet synchronous VFD integrated motor

Featured with excellent performance, reliable operation, convenient use and maintenance, and can accurately adjust the rotating speed according to the load demand, significantly improve the energy utilization efficiency and reduce energy consumption. Its compact design greatly saves the installation space, and is convenient for site layout and maintenance. It is an effective combination of mine frequency converter and motor, and is the preferred solution of underground coal mine drive system, which also solves the field application problems and long-distance drive problems of various mine frequency converters.

Product Features

High efficiency

IE4 and above;
Power factor close to 1;
Comprehensive energy saving 12%-15%
Compact structure

Frequency converter and motor integrated;
Easy and fast installation
Low noise and low vibration

Stable operation;
Significantly lower noise and vibration
Excellent performance

Solves large load starting torque, large power grid impact, large system interference

Working conditions

-20℃ ~+40℃
Ambient air temperature
≤90% (at 25℃)
Humidity
≤1000m.a.s.l.
Altitude

Specifications

Cooling method	IC37W
Power range	200-1600kW(544-2175Hp)
Speed range	1500rpm
Frequency	5-60HZ
Voltage range	1140-3300V
Protection grade	Up to IP66
Explosion proof type	Ex db
Mounting type	IMB3, IMB5, IMB35
Bearing	Rolling bearing
Standards	GB, IEC
Certifications	CCC, MA
