Permanent magnet motors
Low speed permanent magnet direct drive synchronous motors
Compared with the traditional driving system, it directly drives the load, with compact structure and convenient installation, which greatly saves the installation space; The efficiency reaches IE4 and above, and the comprehensive energy saving rate reaches over 30%; Starting with low frequency and large torque, the starting torque can reach 2.5 times, which solves the problem of starting under heavy load.
Product Features
-
High torque densityAdopt water cooling structure;
High torque density.
-
Excellent performanceLow vibration≤1.0mm/s;
High efficiency: IE4 and above;
High torque: up to 3000kN•m
-
Strong overload capacityUp to 2.5 times overload capacity;
Heavy load start can be achieved
-
Easy maintenanceSimpler structure to realize less maintenance workload
Working conditions
-
-20℃ ~+40℃ (Standard)
-40℃ ~+60℃ (Customized)
Ambient air temperature -
≤90% (at 25℃)
Humidity -
≤1000m.a.s.l. (Standard)
1000m.a.s.l.~5000m.a.s.l.(Customized)
Altitude
Specifications
| Cooling method | IC37W, IC46W |
| Power range | 355-3000kW( 480-4000Hp) |
| Frame size | H560-1120 |
| Speed range | 0-200rpm |
| Frequency | 5~150Hz |
| Voltage range | 6000-10000V |
| Protection grade | Up to IP66 |
| Explosion proof type | Ex db |
| Mounting type | IMB3, IMB35, IMV1 |
| Bearing | Rolling bearing |
| Standards | GB, IEC |
| Certifications | CCC, MA |
Applications: Belt conveyors, scraper conveyors, mill, mixers, hoisters
