Motors for explosive atmospheres
WEX3 series low voltage induction motors
WEX3 series of motors is a new generation of ultra-high-efficiency explosion-proof motors, dedicated to providing all-round driving force for the domestic and international markets.
Product Features
-
Original designSeries products from original design
-
Excellent performanceHighly efficient
Low in noise and vibration
Safe and reliable
-
Product featuresWith coal mine safety certification, CQST, ATEX, IEC Ex
-
Wide applicationPlaces with the presence of dangerous explosive gas mixtures
Working conditions
-
-40℃～+60℃Ambient temperature
-
Monthly average ≤90%Humidity
-
≤1000m.a.s.l.Altitude
Specifications
| Frame Size | Cast iron: IEC80 ~ 350 |
| Rated power | 0.18～375kW |
| Rated voltage | up to 1140kV |
| Poles | 2, 4, 6, 8P |
| Efficiency level | IE3 |
| Duty | S1 |
| Mounting option | B3, B5, B35, B14, V1 |
| Insulation | Class F/B, △ T 80K |
| Protection grade | IP55 |
| Cooling method | IC411 |
| Anti-corrosion level | C3 |
| Explosion-proof level | Ex db/eb IIB, IIC and I M2 Ex db I Mb |
| Standards | IEC60034-30-1; IEC 60079-0; IEC 60079-1; IEC 60079-7; IEC 60079-31 |
| Certifications | ATEX, IEC Ex |
| Applications | The main applications including pumps, fans, blowers, crushers, conveyor systems, mills, cranes and other applications located in areas that require explosion proof motors. |
