Three-phase induction motors
TETC series
This product is suitable for various industries and plays a great role in Oil & Gas, Chemical, Coal, Metallurgy, Electric Power, Ports and Machinery industries. It can be used to drive pumps, fans, compressors, conveyors, mixers, crushers, winches and other mechanical equipment.
Product Features
-
High reliabilityReliable insulation and long lifespan;
Robust bearing structure;
-
Excellent performanceHigh efficiency: IE4 and above;
Low vibration: ≤1.2mm/s;
Low noise: ≤Lp85dB(A).
-
Easy maintenanceLarge injection space;
Extended lubrication intervals (1.5x)
Full life cycle services
-
Customized designFlexibel design;
Catering to customer needs
Working conditions
-
-20℃ ~+40℃ (Standard)
-60℃ ~+60℃ (Customized)
Ambient air temperature -
≤90% (at 25℃)
Humidity -
≤1000m.a.s.l. (Standard)
1000m.a.s.l.~5000m.a.s.l.(Customized)
Altitude
Specifications
| Cooling method | IC511, IC516 |
| Power range | 185-4500kW(134-6200Hp) |
| Frame size | H500-1000 |
| Speed range | 300-3600 rpm |
| Frenquency | Fixed (50Hz/60Hz)/Variable |
| Voltage range | 3000-11000V |
| Protection grade | Up to IP66 |
| Explosion proof type | Ex db, Ex tb |
| Rotor material | Cast aluminum/copper bars |
| Mounting type | IMB3, IMB35, IMV1 |
| Standards | GB, IEC, NEMA, BS, API, EN |
| Certifications | IEC Ex, ATEX, CCC, MA, CSA, UL |
